Rotary Ntawv Sheeter 1700mm

HHSDG-1700 yog peb tus qauv muag khoom zoo tshaj plaws. Vim li cas 1700mm? Vim tias nws haum rau feem ntau ntawm cov ntawv ntim khoom yob - los ntawm cov thawv ntim dej haus rau cov thawv ntim khoom rau cov hnab ntim khoom hnyav. Thiab vim hais tias qhov dav 1700mm tseem tswj tau rau feem ntau cov khw hauv pem teb.This Rotary Paper Sheeter 1700mm yog peb qhov zoo tshaj plaws -muag high-end qauv rau 1700mm ntim yob.

1700mm dav

- Npog feem ntau cov niam txiv yob qhov loj me yam tsis muaj pov tseg.

500m / min ceev

- Ua kom muaj kev kub ceev luam ntawv thiab hloov kab.

1200gsm muaj peev xwm

- Kov txhua yam los ntawm cov ntawv sib zog mus rau cov ntawv pallet hnyav.

Splicer npaj

- Koj tuaj yeem ntxiv qhov hloov pauv tsis nres tom qab.

Ib daim ntawv zeb hauv Indonesia khiav 1000gsm kraft rau cov hnab cement. Lawv tau siv cov slitter cais thiab ib daim ntawv - ob tus neeg ua haujlwm, ob lub tshuab, thiab ntau yam khoom siv. Lawv hloov ob qho tib si nrog HHSDG-1700 nruab nrog lub chaw nres tsheb hnyav. Tam sim no ib tus neeg ua haujlwm ua haujlwm, thiab qhov chaw hauv pem teb tau tso tawm rau kev khaws cia. Tus thawj coj tsim khoom tau hais rau peb tias, "Peb txiav peb cov nqi ua haujlwm ib nrab thiab peb cov khoom pov tseg los ntawm 60%.

• Lub thav duab hnyav 21 tons - qhov ntawd yog 3 tons ntau dua li tus qauv ntxaib rotary hauv tib qhov dav. Cov hlau ntxiv dampens vibration thaum txiav hnyav board.
• Lub servo drives zoo ib yam li ntawm 1500mm qauv, tab sis nrog lub zog siab dua los tswj lub vev xaib dav.
• Lub riam lub tog raj kheej muaj cov kabmob loj tshaj plaws rau kev ua haujlwm hnyav hnyav.
• Hniav lub neej tseem zoo li qub: Cr12MoV, rov ua dua txhua 2-3 xyoos, teem lub neej 5-6 xyoo. Txawm hais tias ntawm 500 m / min, cov hniav hnav ib txwm vim tias qhov txiav txiav yog shear, tsis cuam tshuam.

Kev kub ceev splicer

- Rau cov kab txuas ntxiv.

Tag nrho nws pib slitting

- Yog tias koj hloov cov qauv txiav ntau zaus.

Plua plav rho tawm

- Tshwj xeeb tshaj yog rau cov khoom siv rov ua dua tshiab.

Anti-static bars

- Rau cov huab cua qhuav lossis cov ntawv coated.

Extended stacker

- Txog li 1600mm pawg qhov siab.

Kev them nyiaj yug:Cia siab rau Rotary Paper Sheeter 1700mm's 12-hli warranty thiab pub dawb rau cov chaw taws teeb.

CTA:HHSDG-1700 yog lub tshuab ua txhua yam rau kev ntim khoom hloov pauv. Qhia rau peb koj niaj hnub ntim thiab cov khoom sib xyaw - peb yuav tawm tswv yim rau kev teeb tsa.Thov ib nqe lus rau Rotary Paper Sheeter 1700mm hnub no.
